▲Supports the Intel LGA2011 pin-series processors
▲Support 6 SATA interfaces, 4 USB3.0 and 8 USB2.0
▲High speed DDR 3 four-channel memory slot; maximum capacity 128G memory
▲ Support for 5.1 sound channel ALC897 chip ▲ Support for M. 2 SLOT * 2 (SATA + PCIE protocol)
▲ Support for 1 PS / 2 interface
▲ Support for the PCIE expansion slot * 4
▲ Support for RJ 45 Gigabit network card interface * 1
▲ Support for 8-phase power supply, 6-layer floor plate
▲ Support for the Windows10 64-bit operating system
| PRODUCT PROFILE | |||
| PRODUCT NAME | X99-P8D3-V1.0 desktop motherboard | ||
| CPU | Intel LGA2011 Pin-series processor. | ||
| South Bridge | B85 Chipset series | ||
| RAM | Technology | four channels four channels DDR3 1333/1600/1866MHz | |
| Max Capacity | 128GB | ||
| RAM Slot | 4*240PIN DDR3 | ||
| Rear I/O | PS/2 | 1 (PS / 2 mouse, PS / 2 keyboard) | |
| Ethernet | 1 Realtek Gigabit network card | ||
| Audio | 1个(Mic-in, Line-out、Line-in) | ||
| USB | 6个USB2.0，2个USB3.0 | ||
| internal connector | USB2.0 | 2 (one FUSB can be connected to two USB2.0 interfaces); | |
| USB3.0 | 2 (one FUSB can be connected to two USB3.0 interfaces); | ||
| ATXPWR | 1 standard 1 x 8 PIN power outlets; 1 standard 1x24PIN power outlet | ||
| Audio | 1*2*5PIN | ||
| COM | 1*2*5PIN | ||
| JLPC | 1*2*5PIN | ||
| JTPM | 1*2*7PIN | ||
| SFAN | 2*3PIN，1*4PIN | ||
| CFAN | 1*4PIN | ||
| M.2 | M.2 SLOT*2(support PCIE、SATA) | ||
| SATA | 6*SATA port（SATA3.0*4； SATA2.0*2） | ||
| PCIE | 4*PCIE （PCIE X16*2;PCIE X1*1;PCIE X4*1） | ||
| environment | temperature range | work environment | Storage environment |
| Temperature:-10~60℃ Humidity: 5%~95% | Temperature: -40~85℃ Humidity: 5%~95% | ||
| Dimension | size | 283 mm x 216 mm | |
| Product advantages: |
| Well-cooling system with Good thermal material aluminum base for motherboard |
| All-solid electric capacitor for motherboard |
| PCB Copper plating technology for Motherboard |
| Independent power supply designed for Motherboard CPU |
| Zero burning protection circuit for Motherboard |
| Dual safety device stabilize voltage and current for load data uniformly |
| Company advantages |
| 23 YEARS Motherboard FACTORY |
| ECO-ENVIRONMENT MATERIAL |
| CE ROHS FCC ISO CERTIFICATES |
| 50+ R8D DESIGNER TEAM |
| FAST DELIVERY SHIPPING |
| GUARAMTEED AFTER-SALE SERVICE |
