▲support Intel LGA2011-3 Series processor
▲support 3*SATA port ，(1*SATA3.0,2*SATA2.0)
▲support High-speed DDR4 dual-channel
memory slots: supports the maximum frequency
2400MHz, max 128GB
▲support 5.1 channel ALC897 chip
▲support 2*USB3.0，8*USB2.0
▲support 2*PCIE port ：1*X16、1*X1的PCIE
▲support RJ45 Gigabit NIC interface
▲support 4 floors base plate, 6 phase power
supply
▲support Windows 7 and Windows 10 32-bit /
64-bit operating systems
| PRODUCT PROFILE | |||
| Product Name | X99-P4-V1.0 desktop Motherboard | ||
| CPU | Intel LGA2011-3 Series processor | ||
| SouthBridge | H81 Chipset Series | ||
| RAM | Technology | Dual Channel Support maximum frequency 2400MHz | |
| max | 128GB | ||
| RAM Slot | 4 * 288 PIN DDR4 Memory slot | ||
| RearI/O | PS/2 | 1*PS/2 keyboard and a PS/2 mouse | |
| USB | 2*USB3.0；4*USB2.0 | ||
| Ethernet | 1 Realtek Gigabit network card | ||
| Audio | 1*(Mic-in, Line-out、Line-in) | ||
| internal connector | USB 2.0 | 4*(1 FUSB Can be transferred to two USB 3.0 Port) | |
| JLPC | 1*2x5Pin | ||
| PCIe | 2*（1*PCIe x16、1*PCIe x1） | ||
| M.2 | 1*（support PCIE M.2/SATAM.2） | ||
| ATXPWR | 1 standard 1x8PIN power outlet; 1 standard 1x24PIN power | ||
| Audio | 1*2x5Pin | ||
| Dimension | Size | 190MM x 216MM | |
| Shenzhen Anxun Technology Co., Ltd. is one of the leading computer manufacturers in China, located in Shenzhen, China. |
| Our factory was established in 2003 and has a history of 20 years. Since its establishment, |
| we have focused on the production and research and development of computer motherboards, |
| graphics cards, displays, solid-state drives, all-in-one computers, laptops, etc., with a history of 20 years. |
| Office display |
| Product advantages: |
| Well-cooling system with Good thermal material aluminum base for motherboard |
| All-solid electric capacitor for motherboard |
| PCB Copper plating technology for Motherboard |
| Independent power supply designed for Motherboard CPU |
| Zero burning protection circuit for Motherboard |
| Dual safety device stabilize voltage and current for load data uniformly |
| Company advantages |
| 23 YEARS Motherboard FACTORY |
| ECO-ENVIRONMENT MATERIAL |
| CE ROHS FCC ISO CERTIFICATES |
| 50+ R8D DESIGNER TEAM |
| FAST DELIVERY SHIPPING |
| GUARANTEED AFTER-SALE SERVICE |
